Rain Pipe is an affordable spray irrigation technology. It is a replacement for Sprinkler Irrigation System. It is easy to install and maintain. Rain Pipe is flexible hose with pattern of drip holes. These drip holes are made with nano punching technology to ensure uniform flow of water. Rain Hose is suitable for closely spaced crops, onion, vegetable crops, leafy vegetables, groundnut etc.
Rain Hose is an affordable spray irrigation technology. It is a replacement for Sprinkler Irrigation System. It is easy to install and maintain. Rain Hose is flexible hose with pattern of drip holes. These drip holes are made with nano punching technology to ensure uniform flow of water. Rain Hose is suitable for closely spaced crops, onion, vegetable crops, leafy vegetables, groundnut etc.
Considering Spraying width of 5 to 6 meters max. at ~1 kgf. We recommend spacing between Rain Pipe to Rain Pipe max. 5 Meters and Laying length of each line can go up to 60 meters.
| General | |
| Expected Life | 4 Years |
| Suitable Crop | Closely spaced crops, onion, vegetable crops, leafy vegetables, groundnut etc. |
| Specification | |
| Drip Hole Spacing | Continuous pattern of holes approx. 5 cm Spacing. |
| Dripper | No Dripper. Only Simple Laser Punched Holes. |
| Height of Spray | 1.5 to 2 Meter |
| Laying Length | 25 to 50 Meter |
| Number of Rolls per acre | 8 Rolls / 800 Meter |
| Operating Pressure | 1 Kg / cm2 |
| Single Roll size/weight | DN 33 cm Height 9 cm / 4.2 Kg |
| Wall Thickness | 350 Micron |
| Water Discharge | 200 Liter / Hour / Meter of Rain Hose @ 1 Kg/cm2 |
| Width of Spray | 5 to 6 Meter |
| Diameter | 40 mm |
| Packing | |
| Gross Weight | 4.500 Kg |
| Packing Box Size | Carton Packing |
| Roll Length | 100 Meter |
| Net Weight | 4.200 Kg |
